The Acebeam X25 is a high-power, long-range torch designed for exploration and search and rescue. It delivers a maximum light output of 23000 lumens and a beam distance of 1553 metres, and also features an RGB light source beneath the head, offering atmospheric effects for camping and versatile colour light modes including Red, Green, Blue, White, SOS, Red and Blue Flashing, Beacon, Meteor Rotation, and Rainbow Rotation. Power is supplied by a holder for 4 x 21700 5000mAh lithium-ion replaceable batteries, with an alternative battery pack version offering 60W fast charging in just 1.5 hours. It achieves a maximum runtime of more than 10 hours and a peak beam intensity of 602952 candela. The torch has an IP68 ingress protection rating, ensuring durability in challenging environments. Operational control is provided by dual switches on the handle and body, complemented by a detachable handle for ergonomic use. A patented mechanical lock prevents accidental activation, while a power indicator keeps you informed of battery status.
Features
Two LED Options: Choose between 16 x CREE XP-LR LEDs or 16 x Luminus SFT-25R LEDs.
Fast Charging: The built-in battery pack version supports 60W fast charging, reaching full charge in 1.5 hours.
RGB Lighting: Includes RGB lighting beneath the head for atmospheric effects and various signaling modes.
Detachable Handle: Offers ergonomic control with or without the handle, featuring dual switches for versatile operation.
Mechanical Switch Lock: A patented mechanical lock prevents accidental activation, ensuring secure handling.
Package Includes
1 x Acebeam X25
1 x X25 Case
1 x Battery Holder
4 x 21700 5000mAh Rechargeable Li-ion Batteries
2 x A2 Charging and Storage Cases
1 x Detachable Handle
1 x Silicone Protective Cover
1 x Lanyard
2 x Spare O-rings
1 x User Manual
1 x Acebeam X25
1 x X25 Case
1 x 14.4V/4250mAh Battery Pack
1 x USB Charging Cable (USB-A to USB-C)
1 x Charging Adapter
1 x Detachable Handle
1 x Silicone Protective Cover
1 x Lanyard
2 x Spare O-rings
1 x User Manual
Key Information
Feature
Details
Primary Light Source
16 x CREE XP-LR LEDs
Auxiliary Light Source
RGB Light Source
Power Source
4 x 21700 5000mAh Li-ion Battery Holder
Recharging Method
Batteries must be removed and recharged in an external lithium-ion battery charger
Material
Aluminium alloy
Warranty (Torch)
10 years
Warranty (Batteries)
1 year
Warranty (Accessories)
1 year
Feature
Details
Primary Light Source
16 x Luminus SFT-25R LEDs
Auxiliary Light Source
RGB Light Source
Power Source
4 x 21700 5000mAh Li-ion Battery Holder
Recharging Method
Batteries must be removed and recharged in an external lithium-ion battery charger
Material
Aluminium alloy
Warranty (Torch)
10 years
Warranty (Batteries)
1 year
Warranty (Accessories)
1 year
Feature
Details
Primary Light Source
16 x CREE XP-LR LEDs
Auxiliary Light Source
RGB Light Source
Power Source
Customised Rechargeable Li-ion Battery Pack
Recharging Method
USB Type-C
Material
Aluminium alloy
Warranty (Torch)
10 years
Warranty (Battery Pack)
1 year
Warranty (Accessories)
1 year
Feature
Details
Primary Light Source
16 x Luminus SFT-25R LEDs
Auxiliary Light Source
RGB Light Source
Power Source
Customised Rechargeable Li-ion Battery Pack
Recharging Method
USB Type-C
Material
Aluminium alloy
Warranty (Torch)
10 years
Warranty (Battery Pack)
1 year
Warranty (Accessories)
1 year
ANSI/PLATO FL1 Specifications
Feature
Measurement
Maximum Light Output
23000 lumens
Maximum Runtime
10.3 hours
Maximum Beam Distance
1553 metres
Peak Beam Intensity
602952 candela
Impact Resistance
No data
Ingress Protection Rating
IP68
Feature
Measurement
Maximum Light Output
22000 lumens
Maximum Runtime
10.3 hours
Maximum Beam Distance
1505 metres
Peak Beam Intensity
566256 candela
Impact Resistance
No data
Ingress Protection Rating
IP68
Feature
Measurement
Maximum Light Output
23000 lumens
Maximum Runtime
8.67 hours
Maximum Beam Distance
1553 metres
Peak Beam Intensity
602952 candela
Impact Resistance
No data
Ingress Protection Rating
IP68
Feature
Measurement
Maximum Light Output
22000 lumens
Maximum Runtime
8.67 hours
Maximum Beam Distance
1505 metres
Peak Beam Intensity
566256 candela
Impact Resistance
No data
Ingress Protection Rating
IP68
Dimensions
Feature
Measurement
Length
157.5 mm
Head Diameter
92 mm
Weight
1064 g
Feature
Measurement
Length
157.5 mm
Head Diameter
92 mm
Weight
1072 g
Additional Data
FL1 STANDARD
Turbo
High
Med2
Med1
Low
Ultra-Low
Strobe
Max Output
23000-5400 lm
12200-5400 lm
5400 lm
2700 lm
1400 lm
700 lm
23000-5400 lm
Max Runtime
1min+90min
5min+85min
1h 35min
3h 35min
6h
8h 40min
4min+3h
Max Beam Distance
1553 m
1071 m
755 m
517 m
384 m
285 m
Peak Beam Intensity
602952 cd
286760 cd
142506 cd
66822 cd
36864 cd
20306 cd
Notice: The above-mentioned parameters (tested with a 14.4V/4250mAh rechargeable battery pack) have been measured in accordance with the international flashlight testing standard ANSI/ PLATO FL1, and are approximate and may vary from headlamps, batteries, and environments.
FL1 STANDARD
Turbo
High
Med2
Med1
Low
Ultra-Low
Strobe
Max Output
23000-5400 lm
12200-5400 lm
5400 lm
2700 lm
1400 lm
700 lm
23000-5400 lm
Max Runtime
1min+107min
5min+100min
1h 52min
3h 34min
7h
10h 18min
4min+3h 34min
Max Beam Distance
1553 m
1071 m
755 m
517 m
384 m
285 m
Peak Beam Intensity
602952 cd
286760 cd
142506 cd
66822 cd
36864 cd
20306 cd
Notice: The above-mentioned parameters (tested with 4 x 21700 5000mAh Li-ion batteries) have been measured in accordance with the international flashlight testing standard ANSI/ PLATO FL1, and are approximate and may vary from headlamps, batteries, and environments.
FL1 STANDARD
Turbo
High
Med2
Med1
Low
Ultra-Low
Strobe
Max Output
22000-5100 lm
11000-5100 lm
5100 lm
2700 lm
1400 lm
700 lm
22000-5100 lm
Max Runtime
1min+90min
5min+85min
1h 35min
3h
6h
8h 40min
4min+3h
Max Beam Distance
1505 m
1046 m
740 m
510 m
370 m
266 m
1505 m
Peak Beam Intensity
566256 cd
273529 cd
136900 cd
65025 cd
34225 cd
17689 cd
566256 cd
Notice: The above-mentioned parameters (tested with a 14.4V/4250mAh rechargeable battery pack) have been measured in accordance with the international flashlight testing standard ANSI/ PLATO FL1, and are approximate and may vary from headlamps, batteries, and environments.
FL1 STANDARD
Turbo
High
Med2
Med1
Low
Ultra-Low
Strobe
Max Output
22000-5100 lm
11000-5100 lm
5100 lm
2700 lm
1400 lm
700 lm
22000-5100 lm
Max Runtime
1min+107min
5min+100min
1h 52min
3h 34min
7h
10h 18min
4min+3h 34min
Max Beam Distance
1505 m
1046 m
740 m
510 m
370 m
266 m
1505 m
Peak Beam Intensity
566256 cd
273529 cd
136900 cd
65025 cd
34225 cd
17689cd
566256 cd
Notice: The above-mentioned parameters (tested with 4 x 21700 5000mAh Li-ion batteries) have been measured in accordance with the international flashlight testing standard ANSI/ PLATO FL1, and are approximate and may vary from headlamps, batteries, and environments.
Performance and Runtime Disclaimer
How to read the data: The outputs provided above are maximum outputs for each mode, and the runtimes provided are the time it takes to drop to 10% of the initial output. This is in line with the International Flashlight Testing Standard ANSI FL1.
Any visual representations (graphs) of the data are approximate only.
Read more
The actual output of the torch/headlamp is controlled by an in-built temperature regulation system. As the torch/headlamp heats up, the brightness will drop to prevent overheating. The Turbo modes of torches/headlamps usually drop down significantly after anything from 15 seconds to 2 minutes. High modes often also experience a drop down over time. Medium and Low modes, however, can be constant for very close to the length of time specified. As the torch/headlamp cools down, either from being turned off or from being used on a lower output level, you will be able to access higher brightness levels again.
Example: An output of 2000 lumens and runtime of 5 hours does not mean 2000 lumens for 5 hours — it means it starts at 2000 lumens and drops below 200 lumens after 5 hours of continuous use.
Turbo and high modes may be unavailable or limited as the battery gets low on charge.
Exact specifications can vary between torches, batteries, age and environments.
